Automatic Inline Linear Screw Capping Machine

N.K Industries manufactures diverse range of Automatic inline linear Screw capping machine that serve various purposes. Our inline capping machines Model NKLC-100 are very flexible capping machine and can handle a wide range of containers and caps without any change-parts for bottle sizes. Our entire inline capping machine comes standard with spring loaded tightening capping discs. Inline Screw Cappers consist of two components: the base cap tightening unit and the cap sorting system with chute. When integrated together it becomes an automatic capper.

The distinctive feature of our Automatic inline linear Screw capping machine is “no bottle no cap system “and “no change part required” for change in bottle size.

Sailent Feature

cGMP Model, Compact Model.
Parts Coming In Contact With Bottle / Screw Cap Are Made Out Of AISI 304
A Special Background Suppression Sensor Stops Machine Automatically In The Event, There Is No Screw Cap In Delivery Chute.
3 Sets Of Tightening Discs
Various Cap Feeding Option Available Like Vibrator Feeder System, Mechanical Cap Feeder Orientator Or Water Fall Type Elevator.
Tool Less Adjust For Change In Bottle Size.
Distinctively Designed Position System Prevents From Cap Being Jammed.
6 Digit Precise Counting Arrangement Helps To Manage Production Process.
Equipped With Emergency Button For Safety Distress.
All Electrical & Brought Out Items Are Of CE Certified.

Technical Specification

Particular	Specification
Operating Direction	Left To Write
Output	30 To 60 BPM
No Of Tightening Disc	6 Nos (3 Set Of Cap Tightening Device)
Bottle Dia	40 To 80mm (up To 150 Mm In Special Case)
Cap Dia	25 Mm To 50 Mm (up To 100mm Dia In Special Case)
Power Require	2 HP
Dimension	1000 (L) X 800(W) X 1500(H)mm
Net Weight	550 KG
Gross Weight	800 KG
PLC Operation & Acrylic Cabinet	Available On Demand
